Kinesis Racelight Granfondo V3 Titanium Frame
The Kinesis Racelight Granfondo V3 Frame is a road frame & fork constructed from titanium. This titanium road frameset is designed for 700c wheels, uses disc brakes and is finished in black & silver.
The super-versatile, all year titanium mile eater.
- Kinesis Titanium Road Frameset
- Forks included. Fits 700c Disc Brake Wheels
- Was available in 57cm in Black & Silver.
- Designed for Road riding.
Kinesis Racelight Granfondo V3 Frame
AEROgrade brushed Ti3AL/2.5V frame.
Tapered milled head tube with matching full carbon fork.
Internal cable routing for both cable and electronic wires. Integrated Mudguard and Rack mounts. Fantastic tyre clearance for wide tyres and mudguards.
Tapered milled head tube with integrated tapered headset. 31.6mm seatpost fitting. 34.9mm seat clamp (Ti and Ti bolt included ).
Clearance for 30mm tyres. Long drop 47mm - 57mm.
Sizes: 48cm- 51cm - 54cm - 55.5cm - 57cm - 60cm.
Frame: 'Tracer' full-carbon monocoque, taper steerer fork. Ti Clamp. FSA taper 1.5 Headset.
Anodised alloy adjusters. Stainless bottle bolts. Totally new taper head tube.
Machined from billet and engraved with 'Kinesis UK' icon. Now with clearance for 28c [depending on brand] when using full size 'guards [refer to FAQ's 16]. Geometry is set for long-reach [47-57mm] calipers, this gives far more clearance for larger tyres.
New 'Tracer 1.5' Taper 1.5, 450g, monocoque carbon fork with eyelets and clearance for full-size 'guards and long-drop calipers. Tough 7mm dropouts are double-eyeletted to easily accomodate rack and mudguard stays and our own brake bridge gives maximum tyre clearance. Top tube is re-profiled with horizontal ovalisation, giving greater lateral stiffness when out of the saddle, complimenting the new fork and headtube.
Down tube is Bi-ovalised where it meets the BB and Headtube. Increased BB drop for stability at speed, precision cornering and better fit. Welds at highly stressed area's like the head tube and BB are 'double pass', ensuring proper penetration and a decent fillet on the second pass.
Seat stays are curved with a 2m radius, providing silky smooth comfort over long distances. Chain stays are deep section and set wide at the BB for stability, we use 'Bullet' ends to finish them off perfectly. All eyelets are welded, not riveted, so they will never come loose.
There is a 'chain keeper' on the RHS seat stay to neatly hold the chain when the wheel is out. All stops, including down tube adjusters are slotted, making cable servicing much easier, adjusters are high qual. anodised alloy.
Hand brushed finish with heat cured decals.
.. more details.
Racelight Granfondo V3 Frame Specification | |
| Component Type | Frame |
| Frame Type | Rigid Frame |
| Brakes Type | Disc Brakes |
| Frame Material | Titanium |
| Colour | Black & Silver |
| Size | 57cm |
| Gender | Men's |
| Wheel Size | 700c |
| Designed for | Road |
| Brand | Kinesis |
| Retailer | Merlin Cycles |
| RRP | £1750.00 |
| Lowest Price | £1275.00 |
Where to buy the Kinesis Racelight Granfondo V3 Titanium Frame?
As far as I'm aware, this Kinesis Racelight Granfondo V3 Frame deal has expired.
You can see if I have any other suitable Frames.
This Kinesis deal was originally found at Merlin Cycles, costing £1275.00 (down from £1750.00) and was last updated on 31st December 2021.
